INDO FARM 1026E
A tractor specially designed for orchard and vineyard applications. This little master is a real workhorse with a Mitsubishi Euro Stage-V Emission power packed 24.75 HP engine, with an unmatched width of 1070 MM, four-wheel drive and oil immersed brakes. Greater tyre footprint on the ground Improves traction, reduces wheel slip, lowers fuel consumption, covers more ground in lesser time. Available with an option of 3 types of tyres- Agriculture, Industrial & Turf.
Features
THREE SPEED PTO
POWERFUL & FUEL EFFICIENT ENGINE
HEAVY DUTY FRONT AXLE
DRY AIR CLEANER
SPECIFICATIONS
| Standard Fitments Features | ||
|---|---|---|
| ENGINE | ||
| Engine   Power, Ps | 24.75 | |
| Rated   RPM | 2500 | |
| No. of   Cylinders | 3 | |
| Engine   Volume | 1319 | |
| Max   Torque, Nm | 76.3 RPM | |
| PTO | ||
| PTO RPMÂ Â Â Std. | 540, 540E, 1000 | |
| GEARÂ Â Â BOX | ||
| Type | Sliding Mesh | |
| Number   of Speeds | 6F+2R | |
| DIFFERENTIALÂ Â Â LOCK | Yes | |
| BRAKES | ||
| Type | Oil Immersed brakes | |
| HYDRAULICÂ Â Â SYSTEM | ||
| Function | Position and draft   control | |
| Lift   Capacity | 500 Kgs | |
| Steering | Hydrostatic | |
| WHEELÂ Â Â TRACK | Agriculture Tyres | Industrial Tyres |
| Front   Track width | 910 | 980 |
| Rear   Track width | 810 | 1020 |
| TYRE | Agriculture Tyres | Industrial Tyres |
| Front | 6.0-12 | 23x8.5-12 |
| Rear | 8.3-20 | 33x15.5-16.5 |
| DIMENSIONS | Agriculture Tyres | Industrial Tyres |
| Length(mm) | 2740 | 2740 |
| Width(mm) | 1070 | 1400 |
| Height   upto beacon top(mm) | 2520 | 2500 |
| Wheel   base(mm) | 1520 | 1520 |
| Fuel   tank capacity(Ltrs.) | 23 | 23 |
| Tractor   weight with ROPS, Kgs | 930 | 990 |
